Video card Blackmagic Design DeckLink PCI BUS

High quality SD PCI bus card for uncompressed 10 bit video. Connections: SDI Video Input: 1x 10 bit SDI Video Output: 2x 10 Bit AES Audio Output: 2 Channel AES and S / PDIF compatible SDI Audio Input: 8 Channel DV playback via SDI output RS422 port for Mazsteuerung Realtime effects Realtime 3-way color correction 64 bit RGB codec for After Effects Supported standards: SD formats: PAL 625/25, 525 / 29.97 NTSC, 525 / 23.98 NTSC SDI: SMPTE 259M and ITU-R BT.601 SDI Video Sampling / Color Depth: 4: 2: 2/10-bit SDI Color Space YUV (YCbCr) or RGB in Desktop Mode SDI Audio Sampling Rate: 48 kHz and 24 bit. Card Type: "short" PCI 66 MHz. Supported in PCI 66 & 33 MHz slots and PCI-X 133 MHz slots and 100. Signal Processing: Color Space Conversion: Hardware based real-time HD Down Conversion: Only Mac OS X ™ supports software-based real-time rendering for all SD cards. Support for HD 1080 and HD 720 to SD. Real-time effects: Mac OS X ™ uses your own Final Cut Pro HD ™ effects. Mac OS X ™ uses Blackmagic Design Custom RT effects in Final Cut Pro HD ™. Windows XP ™ utilizes Blackmagic Design Custom, uncompressed RT Efffekte in Adobe Premiere Pro ™. Windows XP ™ uses Adobe Echtzeiteffkte in DV Edit Mode mt Adobe Premiere Pro ™. Extras: Software included: Deck Control, Disk Speed ??Test, LiveKey, FrameLink, Blackmagic Treiber.DeckLink HD supports External Key, in combination with Internal Key with Blackmagic LiveKey. Installation: Please note the system requirements for Mac OS X ™ and Windows ™. The "short" PCI 66 MHz card is PCI 66 & 33 MHz slots and PCI-X 133 & 100MHz slots fully supported .. Windows ™ PC must be equipped with a 64-bit PCI-X or PCI slot. The card is compatible with MAC and Windows platform and runs on Apple G5 with OS 10.3 Panther and Windows XP with DirectShow
